Concealed Flat Plate Support (Three Sizes)
or 6 weekly payments from $12.50 learn more
Our concealed Flat Plate Supports are an extra heavy duty floating/hidden stud mounted shelf bracket.
These brackets are suited to support shelves, bench tops, bar tops or cabinets. The concealed brackets are designed to be mounted directly to wall studs behind the gib. Four mounting holes give this bracket a extremely high weight capacity, making it well suited for use with heavier items. When the gib is installed, the brackets protrude out for a shelf of surface to rest on.
These brackets are made of mild steel and powder -coated black. The fixing plate is 6mm thick, 63mm wide and 197mm long.
The bracket is 10mm thick, 63mm wide :
Size 1: 368mm long (300mm from end to mounting plate to end of bracket)
Size 2: 445mm long (380mm from end to mounting plate to end of bracket).
Size 3: 520mm long (455mm from end to mounting plate to end of bracket).
Each bracket has a recessed hole to screw onto the item you are installing.
Four hex wood bolts included per bracket 50mm x 6 gauge.
These brackets if fixed correctly can hold up to 230kg per pair of brackets.
Brackets sold individually.
